QUALITY
Designed for superior durability with an easy-to-identify part number permanently engraved on the rubber. Features 4.5–5.00 mm thick rubber exceeding OEM requirements, 25% stronger 4140-grade steel studs, reinforced composite pistons, and the highest leak test ratio after final assembly.
SPECIFICATIONS
Extended Height: 19.80"
Compressed Height: 6.10"
Top Plate Width: 9.00"
Piston Width: 7.90"
Weight: 17.20 lbs
REPLACEMENT FOR
Hendrickson: S-34733, C-34733
Contitech: 9 10PS-14 5 P 139 H
AS34733, HDV34733, HD34733
FITMENT
Please contact your dealer to obtain the original part number and confirm this air spring as the correct replacement. You may also refer to the diagram image and verify that all specifications match your existing air bag.
Important: Purchasing an air spring by vehicle make and model is one of the most common mistakes. Always match by part number and specifications.
Warning: California Proposition 65
Warning: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
www.P65Warnings.ca.gov
| Brand |
Reference Numbers |
|
Contitech
|
9 10PS‑14.5 P 139 H
|
|
Hendrickson
|
S‑34733, C‑34733
|
| Property |
Value |
|
Extended Height
|
19.80"
|
|
Compressed Height
|
6.10"
|
|
Top Plate Width
|
9.00"
|
|
Piston Width
|
7.90"
|
|
Weight
|
17.2 lbs
|
| Longest Side | 0.00" |
| Median Side | 0.00" |
| Shortest Side | 0.00" |
| Weight | 0.00 lbs |
