Key Features:
Quality:
The part number is permanently engraved on the rubber for easy identification.
Rubber thickness ranges between 4.5 - 5.00 mm, surpassing OEM standards, ensuring superior strength and durability.
Built with 25% stronger 4140 grade steel studs and stronger composite pistons for added robustness.
Undergoes the highest leak test ratio after final assembly to ensure reliability and optimal performance.
Replacement for:
Hendrickson Part Numbers: S-38000, 23-38000, 356-S38000, S38000, 2338000.
Fitment:
Before purchasing, it is recommended to contact your dealer to verify the part number.
Alternatively, check the diagram to ensure all specifications match your current air spring. Avoid purchasing based on vehicle make and model alone, as it can lead to incorrect fitment.
Warning: California Proposition 65
Warning: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
www.P65Warnings.ca.gov
| Brand |
Reference Numbers |
|
Hendrickson
|
S‑38000, 23‑38000, 356‑S38000, S38000, 2338000
|
| Property |
Value |
|
Extended Height
|
19.8"
|
|
Compressed Height
|
6.10"
|
|
Top Plate Diameter
|
9.00"
|
|
Piston Diameter
|
10.24"
|
|
Weight
|
14 lbs
|
No inner box information is available for this product.
| Outer Box |
| Quantity |
Longest Side |
Median Side |
Shortest Side |
Weight |
| 60 |
44.09" |
44.09" |
45.28" |
908.30 lbs |
